Getting Started
Agilent Vapor Generation Accessory VGA 77 and VGA 77P User’s Guide 31
Figure 9. Mark 7 burner with holder in position
Mark VI and VI-A Burners
If you have a Mark VI or Mark VI-A burner, you will need a cell holder
and suitable mounting brackets for these burners. (Refer to Page 79
for ordering information.)
To install these mounting brackets on the burner:
1 Align the burner clamps at either end of the burner, with the
mounting peg pointing inward and the hole in the end of the
plate aligned over the hole in the end of the burner.
2 Use the screws provided to fix the burner clamps in position.
NOTE
The clamps can be left permanently installed since they will not interfere with
normal flame analyses.
