24
26. TiltLight
•Thislightgoesonandthe
alarmbuzzersoundswhenthe
machinetiltsmorethanmax
allowabletiltangle.(See“(7)Tilt
AlarmBuzzer”underSection1of
Chapter3fordetails.)
•Whentheboomisraisedto60°ormore,
thislightflashesandthetravelfunctionis
disabled.(SeeSection3ofChapter3for
details.)
27. Notused
28. OverloadWarningLight
/OilTemperatureLight
 Whentheplatformis
overloaded,thislightflashes,the
alarmbuzzersoundsandallof
thefunctionsaredisabled.
29. DPFRegenerationRequest
/ExhaustTemperatureWarning
Light
•ThislightflasheswhenaDPF
stationaryregenerationis
required.
•WhiletheDPFstationaryregenerationis
working,thelightgoesontoindicatethat
theexhaustgastemperatureisgettinghigh.
Thelightalsogoesonwhentheexhaustgas
temperaturegetshighduringtheDPFreset
regeneration(automaticregeneration).
WARNING
•Whenthislightflashes,immediately
stopusingthemachineandexecutethe
stationaryregeneration.
 Resuminguseofthemachinewhilethe
lightisflashingmayleadtoDPFdamage
orcausefire.
•Whenthelightgoeson,theexhaustgasis
ataveryhightemperature.(Itmaysoarup
to450ºCorso.)
 Itmaycauseafireifanycombustible
objectsareleftinthevicinity.Also,there
isariskofsufferingfromaburnduetothe
hightemperatureexhaustgas.
30. FootSwitch
 Depressthisswitchtooperatethemachine
ontheplatform.
NOTICE
 Operatecontrolswithin20secondsafter
depressingthefootswitch.Failuretodo
so,thepowerindicatorlightstartsflashing
andallcontrolsbecomedisabledeven
whenthefootswitchhasbeendepressed.
(See“(28)PowerIndicatorLight.”)
 Inthatcase,releaseallcontrolsandthen
operateagain.•
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊󱓘󱒅󱓆󱓓󱓉󱒅󱒫󱓚󱓓󱓈󱓙󱓎󱓔󱓓󱓘
