Aichi SP14DJ - Fuse; Control Box

45
3‒6 Fuse
Thefuseholdersarelocatedontheinsideofthe
lowercontrolboxandtheenginecompartment
asshowninthefigurebelow.
Foroptionalequipment,fuseswouldbeinstalled
inotherthanthelowercontrolbox.
Keyswitch
M199212-1
Fig.7‒10Lowercontrolboxinside
M199272-2
Fig.7‒11EngineCompartment
3‒7 Controlbox
Whencleaningthecontrolboxusingthethinner,
donotsplashorspillthinnerontheknobsof
thejoystickcontrollers.Doingsomaycausethe
knobstomelt.
NOTICE
 Thelowercontrolboxisplastic-made.
 Iftheorganicsolventissplashedorspilled
onthelowercontrolboxsurfaces,wipeoff
thesolventimmediately.Leavingadhered
theorganicsolventmaycausethesurfaces
tomelt.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒜󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓔󱓗󱒅󱒲󱓆󱓎󱓓󱓙󱓊󱓓󱓆󱓓󱓈󱓊
