3‒3‒2 LubricateEvery100Hoursor1Month
WARNING
 Performlubricationworkinastablepostureusingascaffoldsuchasstools.Donotclimbup
themachinetolubricateit.
CAUTION
 Donotlubricatewhentemperaturesoutdoorsarebelow-10°C.
Lubricant:Generalgrease Molybdenumgrease 
RotationBearing(bothsides)
ElevationCylinder
LevelingCylinder(Lower)
(behindTurntableCover)
(behindTurntableCover)
FlyJibPivotPin,
FlyJibCylinder,
LevelingCylinder(Upper)
FlyJibCylinder,
PlatformPivotPin
BoomPivotPin,
BoomTelescopingWearPads
BoomTelescoping
WearPads
FlyJibPivotPin
SteeringLinkage(bothsides) SteeringCylinder
