4. Towing
WARNING
•Theoperationtoreleasetheparkingbrake
mustbeperformedbyqualifiedservice
technicians.
•Whentowingonaslope,useatowingbar.
Donotusechains,cables,orwireropesto
towonaslope.Themachinemayrollaway
uncontrollably.Suchaccidentcouldresult
indeathorseriousinjury.
Ifyouareunabletotravelthemachinebecause
ofproblems,itispossibletotowthemachine
providedyoureleasetheparkingbrake.Dothe
following.
4‒1 ReleasingtheParkingBrake
WARNING
 Donotreleasetheparkingbrakeon
slopedground.Themachinemayrollaway
uncontrollably.Suchaccidentcouldresult
indeathorseriousinjury.
CAUTION
•Inordertosteerwhilebeingtowed,be
carefultoavoidhavingthetowrodetc.
comeintocontactwiththemachine.
•Oncetheparkingbrakehasbeenreleased,
donottravelthemachineusingthe
controls.Itwillcausetrouble.
•Aftertowingthemachine,restorethe
parkingbrakeimmediately.
Freetheparkingbrake,thentowthemachineto
escapethemachinefromworkingplace,when
thetravelfunctionisdisabled.
DriveWheels
TravelGearbox
Chocks
ParkingBrakeReleasePlate
Bolts
M199632-1
Fig.9‒7
󱒸󱓙󱓊󱓕󱒅󱒖
 Setupthewheelchocksinfrontandrearofall
tires.
󱒸󱓙󱓊󱓕󱒅󱒗
 Firstlyreleasetheparkingbrakeinoneofthe
drivewheels.
 Removetheboltsthataresecuredtheparking
brakereleaseplateonthetravelgearbox.
󱒸󱓙󱓊󱓕󱒅󱒘
 Reversetheplateandreinstallitfacingthe
convexportiontothetravelgearbox.
ParkingBrakeisavailable Released
ParkingBrakeReleasePlate
M094M220
Fig.9‒8
󱒸󱓙󱓊󱓕󱒅󱒙
 Firmlytightentheboltsandfixtheplate.Now
theparkingbrakeisreleased.
NOTICE
 Makesuretosecuretheparkingbrake
releaseplatewiththebolts.
󱒸󱓙󱓊󱓕󱒅󱒚
 Afterreleasingonewheel,andreleaseallother
wheelsinthesamemanner.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒞󱒅󱒒󱒅󱒪󱓒󱓊󱓗󱓌󱓊󱓓󱓈󱓞󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
