33
󱒸󱓙󱓊󱓕󱒅󱒘󱒙
 Rotatetheboomclockwiseapprox.20°from
rearcenterandraisetheboomuptoapprox.
30°fromhorizontal.
 Result:theoscillationaxlesshouldbelocked.
󱒸󱓙󱓊󱓕󱒅󱒘󱒚
 Traveltheleftsteertireupontoa10cmblock
orcurb.
 Result:themachinechassisshouldbetilted.
10cm
Oscillationaxle
locked
Unlocked
M19CL12-1
Fig.6‒7
󱒸󱓙󱓊󱓕󱒅󱒘󱒛
 Positiontheboomrearcenterwhileintilt
positionandthenoperatethetravelfunction.
 Result:theoscillationaxlesshouldunlockand
themachinechassisshouldbeinlevel.
󱒸󱓙󱓊󱓕󱒅󱒘󱒜
 Traveltogetofftheblockorcurb.
󱒸󱓙󱓊󱓕󱒅󱒘󱒝
 Rotatetheboomcounterclockwiseapprox.
20°fromrearcenterandraisetheboomupto
approx.30°fromhorizontal.
 Result:theoscillationaxlesshouldbelocked.
󱒸󱓙󱓊󱓕󱒅󱒘󱒞
 Traveltherightsteertireupontoa10cmblock
orcurb.
 Result:themachinechassisshouldbetilted.
󱒸󱓙󱓊󱓕󱒅󱒙󱒕
 Positiontheboomrearcenterwhileintilt
positionandthenoperatethetravelfunction.
 Result:theoscillationaxlesshouldunlockand
themachinechassisshouldbeinlevel.
󱒸󱓙󱓊󱓕󱒅󱒙󱒖
 Traveltogetofftheblockorcurb.
󱒸󱓙󱓊󱓕󱒅󱒙󱒗
 Rotatetheboomclockwiseapprox.20°from
rearcenterandraisetheboomuptoapprox.
30°fromhorizontal.
 Result:theoscillationaxlesshouldbelocked.
󱒸󱓙󱓊󱓕󱒅󱒙󱒘
 Traveltheleftsteertireupontoa10cmblock
orcurb.
 Result:themachinechassisshouldbetilted.
󱒸󱓙󱓊󱓕󱒅󱒙󱒙
 Positiontheboomhorizontalwhileintilt
positionandthenoperatethetravelfunction.
 Result:theoscillationaxlesshouldunlockand
themachinechassisshouldbeinlevel.
󱒸󱓙󱓊󱓕󱒅󱒙󱒚
 Traveltogetofftheblockorcurb.
󱒸󱓙󱓊󱓕󱒅󱒙󱒛
 Rotatetheboomclockwiseapprox.20°from
rearcenterandextendtheboomapprox.1m.
 Theoscillationaxlesshouldbelocked.
󱒸󱓙󱓊󱓕󱒅󱒙󱒜
 Traveltheleftsteertireupontoa10cmblock
orcurb.
 Result:themachinechassisshouldbetilted.
󱒸󱓙󱓊󱓕󱒅󱒙󱒝
 Retracttheboomfullywhileintiltpositionand
thenoperatethetravelfunction.
 Result:theoscillationaxlesshouldunlockand
themachinechassisshouldbeinlevel.
󱒸󱓙󱓊󱓕󱒅󱒙󱒞
 Traveltogetofftheblockorcurb.
2‒7 LastCheck
󱒸󱓙󱓊󱓕󱒅󱒚󱒕
 Retracttheboomfullyandlowertheboom
fully.
󱒸󱓙󱓊󱓕󱒅󱒚󱒖
 Putthemachineonafirm,levelsurfaceand
turnthekeyswitchto“ ”(OFF)toshutdown
theengine.
󱒸󱓙󱓊󱓕󱒅󱒚󱒗
 Circlethemachineandcheckvisuallythatthere
arenooilleaks.
Thepre-operationcheckisnowcomplete.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒛󱒅󱒒󱒅󱒵󱓗󱓊󱒒󱓔󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓󱒅󱒨󱓍󱓊󱓈󱓐󱓘
