Aichi SP14DJ - Tie down; Unloading the Machine

72
Tiedownrings
Woodblock
Clearance
※
※
※
M082M651
Fig.10‒4
NOTICE
 Donottightenthetiedownchainsorwire
ropesmarked(※)toomuch.Tightenthem
justsothattheplatformisnotswungor
bouncedduringthetransportation.
4. UnloadingtheMachine
DANGER
•Toavoidslip-offandrun-off,remove
mudoroilfromtiresandramp.Inrainy
condition,donotperformaunloading
worktoavoidslipofftheramp.
•Failuretoavoidthesefallhazardscould
resultindeathorseriousinjury.
WARNING
•Donottravelthemachineonaslopethat
exceedsthemachinegradeability.
 Useawinchforloading/unloading,ifthe
rampistoosteeporslippery.
•Ifthetransportvehicleandtheloading
rampareinclinedtotheleftorright
excessively,thewheelsofthemachine
mayfallofftheramp.
•Donotturnthesteeringofthemachine
whileitisontheramp,becauseofthe
possibilityofafall.
•Whenloading/unloading,besuretohavea
guideassistyousothatthewheelsdonot
fallofftherampandthetransportvehicle
bed.
󱒸󱓙󱓊󱓕󱒅󱒞
 Closetheuppercontrolscoverandsecureit
withatie-downstrap(20‒30mmwideand
madeofnylonorpolyesterwebbing).
NOTICE
 Donottightenthetie-downstraptoo
much.Tightenthetie-downstraptothe
extentthattheuppercontrolscoverdoes
notopenduringtransportation.
󱒸󱓙󱓊󱓕󱒅󱒖󱒕
 Removeallloseitemsfromthemachineand
transportvehiclebed.
3. TieDown
󱒸󱓙󱓊󱓕󱒅󱒖
 Tiedownthechassisofthe
machinetothetransport
vehiclebedsecurely.
M19967-1
Fig.10‒3
󱒸󱓙󱓊󱓕󱒅󱒗
 Tiedowntheplatformsothatitisnotswung
duringthetransportation.Atthistime,besure
toallowtheclearancebetweenthebottomof
theplatformandthetransportvehiclebed.
 Tiedowntheplatformwithplacinga
woodblockundertheplatformtoprevent
theplatformfrombouncingduringthe
transportation.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒕󱒅󱒒󱒅󱒹󱓗󱓆󱓓󱓘󱓕󱓔󱓗󱓙󱓎󱓓󱓌
