Aichi SP14DJ - Lower Controls

25
3. LowerControls
15
16
8
12
9
21 4567
10
11
3
13
17
18
19
14
24 25 27
32
26
31
30
2933
28
B
A
B
A
20
21
22
23
M199B22-1
Fig.4‒3
1. BoomElevationSwitch
 Operatethisswitchupandtheboomwill
raise.Operatethisswitchdownandthe
boomwilllower.
2. BoomRotationSwitch
 Operatethisswitchupandtheboomwill
rotatecounterclockwise.Operatethisswitch
downandtheboomwillrotateclockwise.
3. BoomTelescopeSwitch
 Operatethisswitchtotheleftandtheboom
willretract.Operatethisswitchtotheright
andtheboomwillextend.
4. FlyjibSwitch
 Operatethisswitchupandtheflyjibwill
raise.Operatethisswitchdownandthefly
jibwilllower.
5. EmergencyStopButton
 Pushinthisbuttonto“OFF”
andallfunctionswillstop.Pull
outthisbuttonto“ON”andthe
machinewilloperate.
6. PlatformRotationSwitch
 Operatethisswitchupandtheplatformwill
rotatecounterclockwise.Operatethisswitch
downandtheplatformwillrotateclockwise.
7. PlatformLevelingSwitch
 Operatetheplatformlevelingswitchto
adjusttheplatformlevel.
8. EngineStartSwitch/Emergency
PumpSwitch
•Operatethisswitchupwithout
operatingtheenableswitchand
theenginewillstart.
•Holdthisswitchdownto
operatethemachinewith
emergencypump.(Referto
Chapter9fordetails)
9. Pre-operationCheckSwitch
 Followtheinstructionandhold
thisswitchupwhenthepre-start
checkisperformed.
10. Notused
11. Notused
12. Notused
13. KeySwitchforUpperControl/
Off/LowerControlSelection
•Turnthekeyswitchtotheleft
andtheuppercontrolswill
operate.
•Turnthekeyswitchtocenter
positionandthemachinewillbe
off.
•Turnthekeyswitchtotheright
andthelowercontrolswill
operate.
NOTICE
 Topreventaflatbattery,turnoffthekey
switchwhiletheengineisstopped.The
enginecannotbestartedifthebattery
hasgoneflat.
14. FuseHolder
15. HourMeter
 Thehourmeterworksonly
whentheengineisinmotion.
15. EnableSwitch
 Holdthisswitchuptooperate
themachineontheground.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊󱓘󱒅󱓆󱓓󱓉󱒅󱒫󱓚󱓓󱓈󱓙󱓎󱓔󱓓󱓘
