Aichi SP14DJ - Page 34

26
16. DPFStationaryRegeneration
Switch
 WhentheDPFregeneration
requestlightisflashing,holding
theDPFstationaryregeneration
switchupwardfor3seconds
ormorecausesthestationary
regenerationtostart.
17. NCDSystemFailureLight
 Thislightgoesonintheeventof
aNOxcontroldiagnosticsystem
failure.
WARNING
 Whenthislightgoeson,immediatelystop
usingthemachine.
 Resuminguseofthemachinewhilethe
lightislitmayleadtoenginedamageor
causefire.
18. DPFRegenerationRequest
/ExhaustTemperatureWarning
Light
•ThislightflasheswhenaDPF
stationaryregenerationis
required,followedbybeepingof
thealarm.
•WhiletheDPFstationaryregenerationis
working,thelightgoesontoindicatethat
theexhaustgastemperatureisgettinghigh.
Thelightalsogoesonwhentheexhaustgas
temperaturegetshighduringtheDPFreset
regeneration(automaticregeneration).
WARNING
•Whenthislightflashes,immediately
stopusingthemachineandexecutethe
stationaryregeneration.
 Resuminguseofthemachinewhilethe
lampisflashingmayleadtoDPFdamage
orcausefire.
•Whenthelightcomeson,theexhaustgas
isataveryhightemperature.(Itmaysoar
upto450ºCorso.)
 Itmaycauseafireifanycombustible
objectsareleftinthevicinity.Also,there
isariskofsufferingfromaburnduetothe
hightemperatureexhaustgas.
19. DPFRegenerationApproval/
AbnormalCombustionLight
•Thelightcomesonbyoperating
theDPFstationaryregeneration
switchtostarttheDPFstationary
regeneration.
•ThelightflasheswhenDPFhas
anabnormality,andthustheDPF
regeneration(resetregeneration
andstationaryregeneration)is
notpossible.
CAUTION
 Whenthislightflashes,immediatelystop
usingthemachineandhaveitinspected.
 Resuminguseofthemachinemaycause
damagetoDPFandtheengine.
20. DigitalDisplay
• Undernormalconditions,nothingisshown
onthedigitaldisplay.
• Whenaproblemoccurs,adiagnosticcode
suchas“LMT”or“ERR”willappearonthe
digitaldisplay.Then,athreedigitnumber
relatedtothediagnosticcodewillappear
onthedigitaldisplay.Whenmorethanone
setofdiagnosticcodeandnumberexists,
eachsetwillappearonthedigitaldisplayfor
3secondsbeforechangingontonextset.
Afterthelastsetappears,thebatterylevel
willappearandthenthedisplaywillreturn
backtothefirstset.
NOTICE
 Forthediagnosticcodesandnumbers
andtheirdescriptions,refertoSection
2ofChapter12for“DiagnosticCodes
Chart”.
21. WrenchIcon
 Whenaproblemoccurs,the
wrenchiconwilldisplayonthe
multi-functionIndicator.
22. HourMeter
 Thehourmeterworksonly
whenthemachineisinmotion.
23. HourMeterIcon
 Whenthehourmeterisrunning,
thehourmetericondisplaysand
flashesonthemulti-function
display.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊󱓘󱒅󱓆󱓓󱓉󱒅󱒫󱓚󱓓󱓈󱓙󱓎󱓔󱓓󱓘
