66
󱒸󱓙󱓊󱓕󱒅󱒖
 Pullouttheemergencystopbuttonto“ON.”
󱒸󱓙󱓊󱓕󱒅󱒗
 Depressthefootswitch.
󱒸󱓙󱓊󱓕󱒅󱒘
 Holdtheemergencypumpswitchdown,and
activateeachfunctionatthesametime.
 Theemergencypumpwillturnonwhen
boththeemergencypumpswitchandthe
operationswitchareturnedon.
2‒2 LowerControls(fromGround)
KeySwitch
EmergencyStopButton
EmergencyPumpSwitch
ON
M199622-1
Fig.9‒4
NOTICE
 Whentheupperorloweremergency
stopbuttonispushedinorthekeyswitch
isturnedto“ “(UPPERCONTROLS),
operatingwiththeemergencypumpfrom
thelowercontrolsisnotpossible.
󱒸󱓙󱓊󱓕󱒅󱒖
 Turnthekeyswitchto“ ”(LOWER
CONTROLS).
󱒸󱓙󱓊󱓕󱒅󱒗
 Pullouttheemergencystopbuttonto“ON.”
󱒸󱓙󱓊󱓕󱒅󱒘
 Holdtheemergencypumpswitchdown,and
activateeachfunctionatthesametime.
 Theemergencypumpwillturnonwhen
boththeemergencypumpswitchandthe
operationswitchareturnedon.
3. Overrideswitch
WARNING
 Theplatformoverloadsensingsystem
isdisabledwhentheoverrideswitchis
operated.Donotputmoreweightonthe
platform,orthemachinecouldtipover
resultingindeathorseriousinjury.Retract
theboomfirstandthenlowertheboomto
keeptheworkingradiusinminimum.
NOTICE
 Theoverrideswitchenablesoperation
fromthelowercontrolsevenwhenthe
emergencystopbuttonontheplatform
hasbeenpushedin.
Whenasystemfailureoccurs,thesystemfailure
lightsontheupperandlowercontrolsflashand
somefunctionswillbedisabled.
Lowertheplatformandescapefromthework
siteusingtheoverrideswitch.
SystemFailureLight
M19CH12-1
Fig.9‒5
Override
Switch
System
FailureLight
ON
M19CH22-1
Fig.9‒6
3‒1 Loweringtheplatform
Iftheboomfunctionsaredisabled,lowerthe
platformasfollows:
󱒸󱓙󱓊󱓕󱒅󱒖
 Takethecoveronthelowercontrolpaneloff.
󱒸󱓙󱓊󱓕󱒅󱒗
 Holdtheoverrideswitchandmakesurethat
thewarningbuzzersounds.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒞󱒅󱒒󱒅󱒪󱓒󱓊󱓗󱓌󱓊󱓓󱓈󱓞󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
