Aichi SP14DJ - Appendix D Daily Inspection Check Sheet

87
1. StaticTest(EN280;6.1.4.2.1)
1‒1 SP14DJ
M09YU220
Fig.14‒1
Platform-load[kg] 324(270+20%) Slope[°] 5.0+0.5=5.5
BoomLength Fullyextended+jibhorizontal BoomAngle[°] 5.5
WeatherConditions Outdoor;nowind TestPassed Additionalweightfor
simulatingmanualforcesand
windforce
Table14‒1
Result:testpassed
󱒦󱓕󱓕󱓊󱓓󱓉󱓎󱓝󱒅󱒦
TestReport
󱒦󱓕󱓕󱓊󱓓󱓉󱓎󱓝󱒅󱒦󱒅󱒒󱒅󱒹󱓊󱓘󱓙󱒅󱒷󱓊󱓕󱓔󱓗󱓙
