Aichi SP14DJ - Hoisting with Boom Raised

74
 Justbeforeleavingofftheground,checkthe
balance,andoperatetheboomtoadjustthe
machinelevelasneeded.
A
M19965-1
Fig.10‒6
Table10‒1 HoistingSpecifications
Model SP14DJ
Machineweight* 8450kg
Typeofhitch 4‒legbridle
Min.breakingload
261kN
(26600kgf)
Min.leglength(same
lengthforall)
5m
Centerofgravitytosteer
wheel
(Fig.10‒4,A)
1530mm
* Seetheserialnumberplateforthemachine
weight.
6. HoistingwithBoomRaised
Whenyouareworkinginacrampedlocation,
youmaynothaveenoughroomto
lowertheboompriortohoisting.In
suchcases,itispermissibletohoist
themachinewhiletheboomisstill
up.Proceedasfollows.
• Prepareslingchainsorwireropesaccordingto
Table10‒2.
• Settheboomangleto60°orlower(thatis,at
least10°belowthemaximumraiseangleof
70°).
• Ifslingchainsorwireropescontacttheboom,
placepadsontheboomtoprotectit.
60°
A
Pads
M19966-1
Fig.10‒7
Table10‒2 HoistingSpecifications
Model SP14DJ
Machineweight* 8450kg
Typeofhitch 4‒legbridle
Min.breakingload
216kN
(22000kgf)
Min.leglength(same
lengthforall)
10m
Centerofgravitytosteer
wheel
(Fig.10‒5,A)
1750mm
* Seetheserialnumberplateforthemachine
weight.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒕󱒅󱒒󱒅󱒹󱓗󱓆󱓓󱓘󱓕󱓔󱓗󱓙󱓎󱓓󱓌
