Aichi SP14DJ - Hydraulic Oil Specifications; Check the Battery Fluid Level

36
2‒2‒1 HydraulicOilSpecifications
Selectthehydraulicoiltypesbyreferringtothe
followingfigure:
Table7‒2 HydraulicOilSpecifications
Type Specifiedbrand Grade
Intendedfor
generalusage
ShellTellusS2M22
orequivalent
ISOVG22
Forcold
region
JXTGNipponOil&Energy
HydluxLT15
orequivalent

M094K121
-20 -10 0 10 20 30 40（℃）
Ambientairtemperature
General
ForCold
Region
Fig.7‒3
NOTICE
•Whentheoutdooratmospheric
temperatureislowerthantheserviceable
temperaturerangeofthehydraulicoil
beingusedinthemachine,firstraisethe
hydraulicoiltemperaturebyallowingthe
machinetorunidleforwarmupbefore
startingwork.
•Thehydraulicoiltemperaturecurvediffers
withtheoperationtimeandworkdetails.
Ifthehydraulicoiltemperatureovershoots
inanabnormalwaybythelong-time
operationorbythehighloadwork,
interrupttheworktoallowthehydraulic
oiltemperaturetogodown.
•ContactAICHIoranAICHIdealerforthe
replacementwork.
•Forotheroils,refertoSection3‒3‒1“List
ofRecommendedLubricants”inthis
chapter.
2‒3 ChecktheBatteryFluidLevel
CAUTION
 Thebatteryfluidcontainscorrosiveacid.
Whendealingwiththebattery,always
wearappropriateprotectiveclothingand
equipmenttoprotectyourhands,eyes,
faceandbody,andavoidcontacting
batteryfluid.
󱒸󱓙󱓊󱓕󱒅󱒖
 Checkthebatteryfluidlevelineachcell.It
shouldbebetweenthe“UPPERLEVEL”and
“LOWERLEVEL”lines.
Upperlevel
Ventcap
Lowerlevel
M161C120
Fig.7‒4
󱒸󱓙󱓊󱓕󱒅󱒗
 Whentheamountoffluidnearsthe“LOWER
LEVEL”line,openthecapandfillwithdistilled
watersoitisatthe“UPPERLEVEL”line.
NOTICE
•Ifoperationcontinueswithinsufficient
batteryfluid,thebatterylifeisshortened,
andthebatterymayoverheatand
explode.
•Donotoverfill.
•Donotaddanythingotherthandistilled
water.Failuretoobeythisinstruction
couldshortenthebatterylife.
󱒸󱓙󱓊󱓕󱒅󱒘
 Wipeupanyspillsimmediately.Keepthe
terminalsandtheuppersurfaceofthebattery
clean.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒜󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓔󱓗󱒅󱒲󱓆󱓎󱓓󱓙󱓊󱓓󱓆󱓓󱓈󱓊
