Aichi SP14DJ - Restoring the Parking Brake

69
󱒸󱓙󱓊󱓕󱒅󱒛
 Totowthemachine,connectatowingchain
orbartothetie-downeyesinstalledonthe
chassis.
Front
M199652-1
Fig.9‒9
Rear
M199662-1
Fig.9‒10
󱒸󱓙󱓊󱓕󱒅󱒜
 Removethewheelchockscarefullyandthen
towthemachineslowly.
Releasingtheparkingbrakeisnowcomplete.
4‒2 RestoringtheParkingBrake
WARNING
 Donotrestoretheparkingbrakeon
aslope.Themachinemayrollaway
uncontrollably.Suchaccidentcouldresult
indeathorseriousinjury.
Aftertowingthemachine,restoretheparking
braketofollowtheprocedurebelow.
ParkingBrakeReleasePlate
Bolts
TravelGearbox
DriveWheels
Chocks
M199642-1
Fig.9‒11
󱒸󱓙󱓊󱓕󱒅󱒖
 Setupthewheelchocksinfrontandrearofall
tires.
󱒸󱓙󱓊󱓕󱒅󱒗
 Firstlyrestoretheparkingbrakeinoneofthe
drivewheels.
 Removetheboltsthataresecuredtheparking
brakereleaseplateonthetravelgearbox.
󱒸󱓙󱓊󱓕󱒅󱒘
 Reversetheplateandreinstallitfacingthe
concaveportiontothetravelgearbox.
ParkingBrakeisavailable Released
ParkingBrakeReleasePlate
M094M220
Fig.9‒12
󱒸󱓙󱓊󱓕󱒅󱒙
 Firmlytightentheboltsandfixtheplate.
NOTICE
 Makesuretosecuretheparkingbrake
releaseplatewiththebolts.
󱒸󱓙󱓊󱓕󱒅󱒚
 Afterrestoringonewheel,andrestoreallother
wheelsinthesamemanner.
Restoringtheparkingbrakeisnowcomplete.
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒞󱒅󱒒󱒅󱒪󱓒󱓊󱓗󱓌󱓊󱓓󱓈󱓞󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
