4‒3 PlatformRotatingOperation
WARNING
 Whenrotatingtheplatform,makesureto
stopthemachine,andcheckthesafetyof
thesurroundingarea.
Holdtheenableswitchupto“ON”andoperate
theplatformrotationswitchtorotatethe
platform.
EnableSwitch
PlatformRotationSwitch
M1991F2-1
Fig.8‒40
Platformrotationswitch
Stop
CCW
CW
CW
(Clockwise)
CCW
(Counter-
clockwise)
M098M720
Fig.8‒41
5. PlatformLevelingSystem
5‒1 PlatformLevelAdjustment
Ifthepre-operationcheckrevealsthatthe
platformistilted(front-backtiltofabout3°or
more),adjustitasfollows.
WARNING
•Donotallowanypersonorobjectonthe
platformwhenadjustingfromthelower
controls.
•Donottilttheplatformexcessively
whenadjustingfromtheuppercontrols.
Occupantsandloadwilldumpoutfrom
theplatform.
NOTICE
 Eveniftheplatformtiltisunder3°,adjust
itifthetiltmakesworkhard.
󱒸󱓙󱓊󱓕󱒅󱒖
 Putthemachineonafirm,levelsurface,.
󱒸󱓙󱓊󱓕󱒅󱒗
 Movetheboomtoapositionwhereitiseasyto
adjust.
󱒸󱓙󱓊󱓕󱒅󱒘
 Holdtheenableswitchupto“ON”ordepress
thefootswitch.Operatetheplatformlevel
adjustswitchtoadjusttheleveloftheplatform.
PlatformLevelAdjustSwitch
M1991H2-1
Fig.8‒42
EnableSwitch
PlatformLevelAdjustSwitch
M1991G2-1
Fig.8‒43
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒝󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
