UG-MD16E-EN (V1.3-190708)

MD-16E

Mixer Reference manual

2.8.2 Signal Generator

Use the built-in DSP processor to produce accurate sine, white, pink noise and optionally couple to the

output channels you need, including the FX channel. Provides standard test signals for commissioning

calibration and external devices for the mixer.

Return to the home page.

Set the frequency of the sine wave from 20Hz to

20kHz.

Select the signal type: sine wave, white noise, pink

noise.

Signal wave forms are: sine wave, white noise,

pink noise.

The associated output buses, when highlighted,

indicates that the signal is coupled to the bus. Click

to switch.

Signal generator switch.

Noise generator output gain adjustment.
