Appendix 1. Technical performance parameters
( The key performance parameters are derived from the standard test method. Test equipment: Professional audio analyzer APx525 / SN: APX2-28556 of Audio Precision
Co.,Ltd.,US. All are direct results of unweighted testing. )
A). General specifications
Display screen
6.1" x 3.5" ( 156mm x 90mm ), 7" high-definition color TFT LCD screen and capacitive touch screen.
Faders
100mm electric intelligent control, accuracy = 1024 position, + 10dB to - 60dB / - ∞ , full electric Fader
Audio Input
channels input:
12 channels Mic/Line( XLR/TRS composite balanced interface ), 2 stereo AES( XLR interface ), 1 stereo USB
disk player or bluetooth player.
Audio output
14
channels output:
2 way main output ( XLR balanced port )
2 way auxiliary output AUX1 and AUX2 ( 1/4" TRS balanced port )
4 way auxiliary output SUB1 to SUB4 ( XLR balanced port )
1 stereo AES output ( XLR balanced port )
1 stereo USB disk recording
1 stereo monitor ( 1/4" TRS stereo port and 16Ω minimum impedance headphone )
Input channel
processing
Digital control analog gain adjustment (Gain ), phase adjustment, 4 position source sound section before/after faders,
4-bands parametric equalization ( PEQ ), high-pass filter, low-pass filter, noise gate and compressor.
Output channel
processing
18-bands graphic equalizer( GEQ), high-pass and low-pass filters, 4-bands parametric equalization ( PEQ ),compressor
and delay ( max 500ms ).
Recording function
A stereo dual channel recorder selects a set of 4 stereo bus outputs for Main-L / R and AUX1 / AUX2, SUB1 / SUB2 and
SUB3/SUB4 as recording sound source.
Grouping
6 DCA groups( with mute ) and 3 mute groups
Effectors
2 professional effectors: Chorus, Echo, Flanger, Pitch-shift, Reverb and Stereo Delay, 6 kinds of effect processing, 60
factory presets( FX Presets ) , simple and easy presets for users.
Presets
Presets of mixer: User presets include saving or recalling all mixer parameters from the internal and U disk to mixer.
Channel presets: User channel presets can be saved or recalled from the internal and U disk to mixer.
Scene mode
You can implement [Save] / [Delete] / [Recall] / [Export] / [Import] of the scene.
External control
Apple iPad mixer APP software, which can be accessed from the Wi-Fi hotspot and almost all parameters in mixer are
controlled. The remote operation is easy and pleasant.
Wi-Fi
USB Wi-Fi adapter package is included.
Bluetooth
USB Bluetooth adapter package is included.
Sampling frequency /
quantization bits
48kHz / 24bit
Signal delay
Less than 3.3 milliseconds, from any input to output
Frequency response
+/ - 0.1dB ( 20Hz to 20kHz @+4dBu input, balanced input from MIC/Line to AUX /SUB balanced output, Analog gain=0dB and other level gain=0dB )
THD+N
Less than 0.03% ( 20Hz to 20kHz @+4dBu input, balanced input from MIC/Line to AUX/SUB balanced output, Analog gain=0dB and other level gain=0dB )
Less than 0.009% ( 1kHz @+4dBu input, balanced input from MIC /Line to AUX/SUB balanced output, Analog gain=0dB and other level gain=0dB )
Signal to noise ratio
>95dB( Input level for maximum undistorted output, balanced input from MIC/Line to AUX/SUB balanced output, Analog gain=0dB and other level gain=0dB )
Dynamic range
114dB type, DA converter
>97dB type,(Input level for maximum undistorted output, balanced input from MIC / Line to AUX /SUB balanced output, Analog gain=0dB and other level gain=0dB )
Crosstalk @ 1kHz
< -110dB ( Input level for maximum undistorted output, balanced input from adjacent MIC/line to adjacent AUX/SUB balanced output, Analog gain=0dB,
other level gain=0dB )
Profile dimension
and net weight
438mm( W ) x 455mm( D ) x 145mm( H ) 7.0 kg
Working voltage
85Vac ~ 240Vac, 50 ~ 60 Hz, 50W
MAX
Temperature range
Operating temperature range: 0℃ to 40℃ , storage temperature range: - 20℃ to 60℃
