AIMIX MD-16E - Page 60

-
50
-
UG-MD16E-EN (V1.3-190708)
MD-16E
Mixer Reference manual
B). Analog input characteristics
Input port
Used for
standards
Enter
Impedance
Analog gain
adjustment
range
Analog gain
Input level *
2
Port
Sensitivity *
1
Maximum distortion
before the level
CH01 ~ CH12
50Ω to 600Ω Mics
& 600Ω Line
6.8 kΩ
-5dB ~ +58dB
1dB / Class
+58dB
-74dBu (154uV)
-34.5dBu (14mV)
XLR / TRS
Mixed and
balanced
-5dB
-11dBu (218mV)
+24.2dBu (12.5V)
*
1
. Sensitivity means that the minimum input level of output +4dBu (1.23V) can be generated when the mixer is set to the maximum gain ( all faders and level controllers are at the maximum
position, Output channel gain is 0dB )
*
2
. Level uV, mV, V are RMS, i.e. uVrms, mVrms and Vrms.
C). Analog output characteristics
Output port
Used for standards
Output
impedance
Output level *
1
Port
Rated
Maximum distortion
before the level
AUX1 ~ AUX2
600Ω line
75Ω
+4dBu (1.23V)
+23dBu (11V)
1/4" TRS (Balance)
SUB1 ~ SUB4、Main-L/R
600Ω line
75Ω
+4dBu (1.23V)
+23dBu (11V)
XLR-3-32 (balanced)
Phones
32Ω Phone
51Ω
0.82Vrms / 21mW*
2
1.83Vrms / 105mW
1 / 4" TRS
(Stereo, Unbalanced)
300Ω Phone
51Ω
1.76Vrms / 10mW*
2
5.52Vrms / 100mW
*
1
. Level uV, mV, V are RMS, i.e. uVrms, mVrms and Vrms.
*
2
. The position of the level control is -10dBfs.
D). Digital input / Output characteristics
Digital port
type
Format
Data length
Sampling frequency
Level
Port
AES-In1 / AES-In2
AES / EBU
AES / EBU
Professional
application
16 to 24 bit
Digit self adaption
28kHz to 216kHz
Sampling rate self adaption
RS422,
transformer
separation
XLR-3-32
(balanced)
AES-Out
24 bit
48kHz
