- 6 -
PREPARATION
How to read screen
The screen of the station is a touchscreen. Simply tap the icons or buttons displayed on the screen.
The following are examples of typical screens and icons.
* The displayed screens and icons may differ depending on the devices connected to this system.
MENU screen
This screen appears when the monitor is turned on.
Tap to record the currently displayed
video.
*
will be lit in red while recording.
Monitor (
ĺ
P. 28)
Tap to monitor the entrance station.
Recording List (
ĺ
P. 29)
Tap to play recordings.
* This icon blinks when there is a recording that has not been played yet.
Noti¿ cation (
ĺ
P. 34)
Tap to display the noti¿ cation list.
* This icon blinks when a new
noti¿ cation has arrived.
Settings (
ĺ
P. 35)
Tap to con¿ gure the settings.
Tap to con¿ gure the screen brightness,
receiving volume, etc. (
ĺ
P. 25)
Doctor call (
ĺ
P. 22)
Tap to activate or disactivate the doctor call.
* Depending on settings, this icon may not be shown.
O
Tap to turn the monitor o .
Tap to return to previous screen or
undo the last action.
Tap to apply or con¿ rm.
*
(deleting all recordings) will
be shown when the recording list
is displayed.
Tap to return to the previous page. Tap to move to the next page.
Tap to move to the MENU screen.
Set whether or not to enable mobile
device to receive calls from the
entrance station and guard station.
Option (
ĺ
P. 22)
Tap to activate the connected
external device.
* Depending on settings, this
icon may not be shown.
Displayed when a microSDHC card is installed and available.
*
will be shown while a read or write operation is performed on
a microSDHC card. Do not remove the microSDHC card while
this icon is displayed. Otherwise, the data may be damaged.
* will be shown when a non-conforming microSDHC card
is installed. (
ĺ
P. 8)
Hearing aid icon
(*1)
(GT-1C7W-L only)
Displayed when the ringtone is set to mute.
Indicates the Wi-Fi signal strength when the
station is connected to the network. (
ĺ
P. 10)
Indicates the number of the mobile device
registered to the station.
Current date and time
By tapping this, you can set the
current date and time. (
ĺ
P. 38)
While communicating with the entrance station
Navigation buttons
*
t
here is a record
ing
.
that has not been
pl
aye
d y
et.
o
ti
¿
c
e
n
a
ved
ation list.
a
n
e
w
Door release (
ĺ
P. 22)
Tap to unlock the door at the entrance station.
Tap to answer a call.
Tap to call the guard station.
* Depending on settings, this icon
may not be shown.
Option (
ĺ
P. 22)
Tap to activate a connected external
device.
Tap to switch the display mode
between zoom and wide. (
ĺ
P. 23)
NOTE:
Do not puncture the LCD screen with a sharp object. If the screen is punctured, it may result in injury.
(*1): This station emits an electromagnetic field for hearing aids equipped with T-mode to produce clear audio.
