Use and Maintenance Manual – Series X – XS E RESTYLING
Page 109
11. HYDRAULIC DIAGRAM
HYDRAULIC DIAGRAM - STANDARD MACHINES
X8EN – X8EW-WIND – X10EN – X10EW – X10EW-WIND – XS7 E RESTYLING – XS8 E RESTYLING LIGHT
XS8 E RESTYLING – XS8 E RESTYLING WIND
BR1 / BR2
PARKING BRAKES
BV1
BRAKE RELEASE SWITCH FOR EMERGENCY TOWING
CB1 / CB2
BRAKING VALVES
CIL1
STEERING CYLINDER
CIL2
LIFTING CYLINDER
CM
PRESSURE GAUGE CONNECTION 1/4” BSP
DV1
FLOW DIVIDER
EM1
ELECTRIC MOTOR
EV10A
SOLENOID VALVE, SERIES-PARALLEL TRACTION
EV10B
BYPASS SOLENOID VALVE FLOW DIVIDER
EV2
FORWARD DRIVE SOLENOID VALVE
EV3
BACKWARD DRIVE SOLENOID VALVE
EV4
LIFTING SOLENOID VALVE
EV5
LOWERING SOLENOID VALVE
EV8
RIGHT STEERING SOLENOID VALVE
EV9
LEFT STEERING SOLENOID VALVE
F1
SUCTION FILTER
F2
FILTER SCREEN GROUP DROP COMMANDS
GD1
HYDRAULIC CONTROL UNIT
GD2
LOWERING CONTROL INTEGRATED ASSEMBLY
HM1 / HM2
DRIVE MOTORS
NR1
UNIDIRECTIONAL VALVE DESCENT LINE
P1
GEAR PUMP
PM1
EMERGENCY MANUAL DRIVE PUMP
RV1
Pressure relief valve calibration
RV2
MAXIMUM PRESSURE VALVE LIFT CIRCUIT
SEL1
BRAKE SELECTOR VALVE
ST1
CHOKE LINE OF STEERING
ST2
CHOKE LINE COMPENSATION DIVIDER
ST3
CHOKE BRAKES
ST4
DESCENT LINE CHOKE
T1
OIL TANK WITH HATCH
