Use and Maintenance Manual – Series X – XS E RESTYLING
Page 59
5.7 Socket for electric tool connection (optional)
5-8: Platform current socket
5-9: Electric line connection plug
The work platform can be equipped with a socket (230V Ac) enabling the operator to connect the electric tools necessary to carry
out his operations.
To activate the electric line (see pictures above) introduce a cable into the plug connected to the 230V AC 50 Hz mains, with all
protections according to the current standards in force.
The plugs and sockets equipped on standard machines comply with EEC standards and can therefore be used in EU member
countries. On request the machine can be equipped with plugs and sockets in compliance with local standards or with particular
needs.
Connect to the power mains having the following features:
- Power voltage 230V ± 10%.
- Frequency 50÷60 Hz.
- Activated grounding line.
- Working protection devices according to current standards in force.
- Do not use extension leads exceeding 5 metres to connect to the mains.
- Use a cable of suitable section (min 3x2.5 mm
2
).
- Do not use rolled-up cables.
5.8 End of work
After stopping the machine according to the instructions given in the previous paragraphs:
▪ Always set the machine to rest position (platform completely lowered).
▪ Press the emergency Stop button on the ground control panel.
▪ Remove the keys from the control panel to prevent unauthorized people from using the machine.
▪ Recharge the battery according to the instructions given in section "Maintenance".
