7.3.3 Hydraulic circuit oil level check and change
At least every month, check the level in the tank (Figure 7-6), through the little window of the X series or by unscrewing the cap in
the XS E RESTYLING series. Make sure this is always between max and min. If necessary top up until max. level is reached. The
oil check should be carried out when platform is completely lowered.
Completely change the hydraulic oil at least every two years.
To empty the tank (figura 7-7):
▪ Lower the platform completely.
▪ Stop the machine by pressing the emergency stop button on the ground control panel.
▪ Disconnect the tubes from the tank.
▪ Unscrew flange A unlocking the screws with a Phillips screwdriver.
▪ Remove the tank from its seat after removing bar C.
▪ Pour the tank content in a suitable container, through the filler cap.
Use only the types of oil and quantity indicated in the table below.
The lubricants, hydraulic oils, electrolytes and all detergent products should be handled with care and disposed of in safety
according to the current regulations. A prolonged contact with the skin may cause irritations and dermatosis; wash with water and
soap and rinse thoroughly. Contact with eyes, especially with electrolytes, is also dangerous; rinse with water thoroughly and call
the doctor.
