In the event of a fault, carry out the following operations to tow
the machine:
▪ Hook the machine to the provided holes (the same used for
lifting – see previous pictures).
▪ Screw knob B completely on the hydraulic block.
▪ Screw lever C on manual pump A.
▪ Activate the manual pump until the control is bound; by
doing so the parking brakes are unlocked.
▪ Tow at a very slow speed (remember that when the
machine is being towed, brakes are out of order).
At the end of towing operation, resume initial conditions:
▪ Unscrew knob B completely.
▪ Remove lever C from the manual pump and set it to the
position as shown in the figure.
Tow at a very slow speed (remember that when the machine is being towed, brakes are out of order).
Tow only on a flat ground.
Do not park the machine without brakes on. Should the brakes be completely out of order put wedges under
the wheels to prevent the machine from moving accidentally.
