2.6 Model X8EW WIND
X8EW WIND
Maximum working height
8.3
m
27 ‘9”
ft
Max. platform height
6.3
m
20 ‘6”
ft
Ground clearance (pot-hole guards lifted)
100
mm
3.9”
in
Ground clearance (pot-hole guards lowered)
15
mm
.5.9”
in
Platform height for safety speed activation
1.8
m
5 ’9”
ft
Internal steering radius
0
m
0
ft
External steering radius
2.43
m
7 ‘8”
ft
Maximum capacity (m)
500
kg
1100
lbs
Max. number of people on the platform (n) – indoors
3
3
Tool and material weight (me) ** – indoors
260
kg
573.2
lbs
Max. number of people on the platform (n) – outdoors
2
2
Tool and material weight (me) ** – outdoors
340
kg
759.5
lbs
Maximum slide-out extension deck
1.5
m
4 ‘9”
ft
Maximum capacity on deck extension
500
kg
1100
lbs
Maximum amount of people on deck extension - indoors
3
3
Maximum amount of people on deck extension - outdoors
2
2
Maximum drive height
Max
Max
Maximum platform dimensions (extended)
1.2 x 3.75
m
3 ‘9” x 12 ‘3”
ft
Max. hydraulic pressure
230
bar
3335.8
psi
Max. pressure of lifting circuit
160
bar
2320.6
psi
Min. pressure of braking circuit
60÷70
bar
870.2 ÷ 1015.2
psi
Tyre dimensions
Ø410 x 150
mm
Ø16.1” x 5.6”
in
Type of tyres
Cushion soft
Cushion soft
Transport dimensions with removable rails installed *
1.2X2.4X2.24
m
3 ‘9”x 7 ‘8”x7 ‘3”
ft
Transport dimensions with removable rails not installed *
1.2X2.4X1.30
m
3 ‘9”x 7 ‘8”x 4
‘2”
ft
Transport dimensions with folded-down rails (optional) *
1.2X2.4X1.74
m
3 ‘9”x 7 ‘8”x5 ‘7”
ft
Machine weight (unloaded)
2250
kg
4960.4
lbs
Stability limit:
Longitudinal inclination
4
°
4
°
Transversal inclination
2
°
2
°
Maximum wind speed
12.5
m/s
27.96
mph
Maximum manual force - indoors
400
N
90
lbf
Maximum manual force - outdoors
400
N
90
lbf
Max. load per wheel
1200
Kg
2600
lbs
Performance:
Standard battery capacity and voltage
4 x 6 / 200
V/Ah
4 x 6 / 200
V/Ah
Total electrolyte quantity of standard battery
4 x 6.4
Lt.
1.3x 1.6
gal
Standard battery weight
4 x 32
kg
8.8 x70.5
lbs
Optional battery capacity and voltage
4 x 6 / 280
V/Ah
4 x 6 / 280
V/Ah
Total electrolyte quantity of optional battery
4 x 10.3
Lt.
1.3 x 2.7
gal
Optional battery weight
4 x 47
kg
4x104
lbs
Single-phase battery charger
24 / 25
V/A
24 / 25
V/A
Max. current absorbed by the battery charger
12
A
12
A
Electric pump power
3
kW
4.0
hp
Max. absorbed current
160
A
160
A
Max. drive speed
3
km/h
1.9
mph
Safety drive speed
0.6
km/h
0.4
mph
Lowering/lifting time (unloaded)
47 / 47
Sec.
47 / 47
Sec
Oil tank capacity
30
Lt.
7.9
gal
Gradeability
25
%
25
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F
( * ) removing the ladder, the machine overall dimensions are further reduced (length = 2.25 m)
( ** ) me = m – (n x 80)
