6.2.2 Fold-down rails (optional)
The machine can be fitted with rails (optional) folding down to the inside of the platform. By folding down the rails the machine
height can be reduced for:
▪ carriage
▪ passage through lowered areas (e.g. doors)
To fold down the rails, referring to the pictures of the next page:
1. Extend the mobile platform and lock it in the indicated position.
2. Remove the control panel.
3. Raise and turn the front rail to the inside.
4. Remove the locking pins of the two side sliding rails.
5. Turn to the inside and press downwards the side sliding rails.
6. Remove the locking pins of the entrance rail.
7. Raise and turn the entrance rail to the inside.
8. Remove the locking pins of the two fixed side rails.
9. Lift and turn the two side fixed rails to the inside.
10. Close the slide-out extension deck (in the “XS E RESTYLING” series this remains extended by one step).
To restore the initial condition, repeat the a.m. operations in reverse order.
Make sure the rails are properly secured before using the machine.
WARNING!
THIS OPERATION IS ONLY FOR REDUCING THE HEIGHT OF THE STOWED MACHINE TO FACILITATE
CARRYING OPERATIONS.
IT IS ABSOLUTELY FORBIDDEN TO LIFT THE UNIT WITH PERSONNEL ON THE PLATFORM IF THE RAILS
ARE NOT RAISED.
