2.3 Model XS8 E RESTYLING
Dimensions:
XS8 E RESTYLING
Maximum working height
8.03
m
26 ‘3”
ft
Max. platform height
6.03
m
19 ‘7”
ft
Ground clearance (pot-hole guards lifted)
72
mm
28”
in
Ground clearance (pot-hole guards lowered)
15
mm
5.9”
in
Platform height for safety speed activation
1.80
m
5 ‘9”
ft
Internal steering radius
0.60
m
1 ‘9”
ft
External steering radius
2.05
m
6 ‘7”
ft
Maximum capacity (m)
250
kg
551.5
lbs
Max. number of people on the platform (n) – indoors
2
2
Tool and material weight (me) ** – indoors
90
kg
198.4
lbs
Max. number of people on the platform (n) – outdoors
-
-
Tool and material weight (me) ** – outdoors
-
-
Maximum slide-out extension deck
1
m
3 ‘2”
ft
Maximum capacity on deck extension
250
kg
551.5
lbs
Maximum amount of people on deck extension
2
2
Maximum drive height
Max
Max
Maximum platform dimensions (extended)
0.76 x 2.65
m
2 ‘4” x 98 ‘6”
ft
Max. hydraulic pressure
260
bar
3770.9
psi
Max. pressure of lifting circuit
210
bar
2320.6
psi
Min. pressure of braking circuit
65 ÷ 70
bar
942.7 ÷ 1015.2
psi
Tyre dimensions
Ø305-100
mm
Ø12.0”-v3.9”
in
Type of tyres
Cushion soft
Cushion soft
Transport dimensions with removable rails installed *
0.765 x 1.82 x 2.24
m
2 ‘5”x5 ‘9”x 7
‘3”
ft
Transport dimensions with removable rails not installed *
0.765 x 1.82 x 1.32
m
2 ‘5”x5 ‘9”x 3
‘9”
ft
Transport dimensions with folded-down rails (optional) *
0.765 x 2.04 x 1.87
m
2 ‘5”x6 ‘6”x 5
‘7”
ft
Machine weight (unloaded)
1770
kg
3902.1
lbs
Stability limit:
Longitudinal inclination
2
°
2
°
Transversal inclination
2
°
2
°
Maximum wind speed
0
m/s
0
mph
Maximum manual force:
400
N
90
lbf
Max. load per wheel
1000
Kg
2200
lbs
Performance:
Standard battery capacity and voltage
4 x 6 / 200
V/Ah
4 x 6 / 200
V/Ah
Total electrolyte quantity of standard battery
4 x 6.4
Lt.
1.0 x 1.6
gal
Standard battery weight
4 x 32
kg
8.8 x 70.5
lbs
Optional battery capacity and voltage
N.A.
V/Ah
N.A.
V/Ah
Total electrolyte quantity of optional battery
N.A.
Lt.
N.A.
gal
Optional battery weight
N.A.
kg
N.A.
lbs
Single-phase battery charger
24/25 HF
V/A
24/25 HF
V/A
Max. current absorbed by the battery charger
12
A
12
A
Electric pump power
3
kW
4.0
hp
Max. absorbed current
160
A
160
A
Max. drive speed
3.6
km/h
2.2
mph
Safety drive speed
0.6
km/h
0.4
mph
Lowering/lifting time (unloaded)
17 / 24
Sec.
17 / 22
Sec
Oil tank capacity
20
Lt.
5
gal
Gradeability
24
%
30
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F
( * ) removing the ladder, the machine overall dimensions are further reduced (length reduced by 0.17 m)
( ** ) me = m – (n x 80)
