Use and Maintenance Manual – Series X – XS E RESTYLING
5.3 Platform access
The “access position” is the only one from which loading or unloading of persons and materials is allowed. The “access position” to
the work platform is the completely lowered configuration.
To access the platform (Figure 5-4):
▪ Get on ladder A hanging on to the rungs, the ladder stringers
or the entry guard rails.
▪ Raise bar B and get on board.
Check that, once you are on the platform, the bar falls down
closing the access. Fasten the safety harness to the provided
hooks.
To get on the platform use only the
access equipment the platform is
provided with.
When moving up or down, always keep
your eyes on the machine and hold onto
the entry stringers.
IT IS FORBIDDEN
Lock the closing bar so as to keep the
platform access door open.
IT IS FORBIDDEN
To leave or access the work platform
unless this is in the position required for
access or leaving.
5-4: Platform access position/leaving position
5.4 Machine start-up
To start the machine the operator shall:
▪ release the emergency stop button on the ground control panel by rotating it of 1/4 turn clockwise;
▪ turn the on-off key on the ground control panel to "Platform" position;
▪ remove the starting key and hand it over to a person in charge on ground, properly informed of the use of the emergency
controls;
▪ get onto the platform;
▪ Release the emergency stop button on the platform control panel (see previous paragraphs).
At this point the various functions can be performed by thoroughly following the instructions given in the previous paragraphs.
To turn on the machine, the battery charger must be disconnected from the mains (see paragraph 7.4.3). If the
battery charger is working, the machine is off and cannot be turned on.
