0-10 V FANCOIL CONTROL GATEWAY (AZVAFGTF10)
Control gateway of air-to-water zoning units. Fan control through 0-10 V output and opening-
closing electrovalves. Compatible with 2-pipe and 4-pipe installations. Externally powered at
110/230 Vac. Mounted on DIN rail or on wall.
Functionalities:
• Two relays for electrovalve control by demand.
• 0-10 V output for fan control.
• Automatic speed control based on the zones on demand.
5-RELAY FANCOIL CONTROL GATEWAY (AZVAFGTF5R)
Control gateway for air-to-water air conditioners. Control up to three fan-speeds and the
opening and closing of valves. Compatible with 2 pipes or 4 pipes air conditioners.
Externally power supplied at 110/230. Mounted on DIN rail or on wall.
Functionalities:
• Two electro-valve control relays for demand.
• Three control relays for fan-speed selection.
• Automatic speed selection according to the number of zones on demand.
WEBSERVER AIRZONE CLOUD ETHERNET/WIFI (AZVAFWSCLOUD [C/R])
Webserver for controlling Airzone systems through Airzone Cloud platform. Accessible through browser or App (available for
IOS and Android). Connected to router via Ethernet (AZVAFWSCLOUDC) or WiFi (AZVAFWSCLOUDR). Powered through
automation bus.
Functionalities:
• Control of up to 32 systems.
• Configuration and control of zone parameters (Room and set-point temp., operating mode, etc.) and system
parameters via Airzone Cloud.
• Temperature and operating mode time schedules.
• Multi-user and multi-session.
• External control through Airzone Cloud platform.
• Remote updates of the Webserver firmware and the systems connected to it.
• Remote error detection and error resolution.
