47
RELAY RADIANT HEAT CONTROL MODULE (AZVAF5OUTPUTS)
The relay radiant heat control modules have integrated LEDs that detect unusual operations.
Fig. 60
Data transmission from thermostat
Data reception from thermostat
Data transmission from Airzone connection bus
Data reception from Airzone connection bus
Data transmission from gateway
Data reception from gateway
Wireless data packets reception
Association channel active
Data reception from Airzone connection bus
Data transmission from Airzone connection bus
