36
- Insert the battery to supply the thermostat.
- Press the LED to begin the wireless search. The LED will blink in green.
IMPORTANT: The thermostat will display first the wireless zone modules which are closer to it. Remember to configure
this thermostat near the wireless zone module to associate for greater comfort.
-
will show the signal level of this module:
o Low signal range level (It is not recommended to perform the association).
o Medium signal range level.
o Good signal range level.
o Excellent signal range level.
- Press the LED to confirm the association, otherwise use to select another module.
- The number of the zone which associates with the thermostat is the lowest free available number.
- If the association is correct, the LED will flash green 5 times. If it flashes red twice, it means the thermostat is out of
range.
REMEMBER: Is required to set the Main ID parameter of the Lite Thermostat for its proper functioning (see section
Advanced
settings Blueface thermostat
,
Zone settings
).
Configure other functionalities of the LITE thermostat from the advanced configuration menu of a Blueface thermostat (see
section
Advanced settings
,
Zone settings
) or Webserver Cloud (See Webserver Cloud installation manual).
IMPORTANT: For changing the zone address, access the parameter Zone ID, inside the advanced settings menu from a
Blueface thermostat (see section
Advanced settings
,
Zone settings
).
Lite thermostat reset
To reset to factory values of any Lite thermostat, turn up the microswitch 8 and place the thermostat on the base again. Press
on , the LED will flash green twice when the reset process is completed.
INITITAL CONFIGURATION EVALUATION
Check the following aspects:
- AC unit-system communication: Choose any mode (except for STOP mode) and switch on the zone to generate
demand. Verify that the selected operation mode in the Main thermostat is shown in the indoor unit thermostat and
the set-point temperature changes.
- Opening-closing of the dampers, ON/OFF of individual AC units and control outputs: Turn on the system and generate
demand in all the zones. Then, switch off and on each zone to verify the element to be controlled operates properly.
- Verify that the static pressure of the duct system complies with the air distribution network conditions where is
).
Important: After the setup or in case of power outage, the system takes a few minutes to measure precisely the temperature
and the relative humidity.
