31
Fig. 53
Note: For a proper operation of this module, all the control boards must be addressed (see section Advanced Settings).
Configuration
To configure it, follow the steps described in the installation manual, available at myzone.airzoneusa.com.
BACNET INTEGRATION GATEWAY (AZVAFBACNETG)
All Airzone systems must be connected to internet to offer technical support.
It is only necessary to connect one BACnet integration gateway per system.
Assembly
The BACnet integration gateway is integrated into the automation bus of the main
board (Fig. 55). It has a 5-pin terminal, disconnect the terminal and insert the
connector.
Configuration
To configure it, follow the steps described in the installation manual, available at
myzone.airzoneusa.com.
