5-RELAY FANCOIL CONTROL GATEWAY (AZVAFGTF5R)
The 5-Relays Fancoil control gateways incorporate LEDs that detect malfunctions.
Fig. 79
ETHERNET/WIFI CLOUD WEBSERVER (AZVAFWSCLOUD [C/R])
Airzone Cloud Webservers incorporate LEDs that detect malfunctioning.
Data reception from AC unit bus
Data transmission from AC unit bus
Data transmission from domotic bus (input and output)
Data reception from domotic bus (input and output)
Connected to the Internet
Network data transmission
Configured as IP address through DHCP
Configured as Fixed IP address
