Important: We recommend using of top-brand batteries. Using low-quality batteries may reduce the duration of use.
Remember to deposit the old battery into an appropriate recycling point.
0-10 V FANCOIL CONTROL GATEWAY (AZVAFGTF10)
Fig. 37
Assembly
The 0-10 V control gateway is mounted on DIN rail (Fig. 38) or on wall (Fig. 39). This module is externally powered at 110/230
Vac. It is should be placed and mounted in accordance with the current electrotechnical regulations.
Fig. 38 Fig. 39
Note: To remove the module on DIN rail, pull the tab down to release it.
