AJA HDR Image Analyzer User Manual

HDR Image Analyzer v1.0r3 42 www.aja.com
Appendix A – Specifications
HDR Image Analyzer Specs
Video Formats
• (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60
A/B
• (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
• (HD) 1080i 50, 59.94, 60
• (HD) 1080PsF 23.98, 24, 25, 29.97, 30
• (HD) 1080p 23.98, 24, 25, 29.97, 30, 50 A/B, 59.94 A/B, 60 A/B
• (HD) 720p 50, 50.94, 60
Video Input Digital
• 4x 3G-SDI BNC
Video Output Digital
• 4x 3G-SDI BNC
Audio Input Digital
• 16-Channel 24-bit SDI embedded, 48 kHz synchronous
Audio Output Digital
• 16-Channel 24-bit SDI embedded, 48 kHz synchronous
Computer Monitor Output
• DisplayPort Output:
• Up to UltraHD 60p
Reference Input
• Signal: Analog video sync (Blackburst or Tri-Level)
Size: (w x d x h)
• 1RU form factor
• 17.2” x 16.9" x 1.7" (436.88 x 429.26 x 43.18 mm)
Weight
• 28 lb (12.7kg) in box
• 18 lb (8.2kg) server only
Power
• 100-240 VAC 50/60 Hz (Dual, redundant power supplies)
• 190W typical, 245W Maximum
