AJA HDR Image Analyzer User Manual

HDR Image Analyzer v1.0r3 39 www.aja.com
Setup Menu Guide
Table 6. Analyzer Mode > Audio, Timecode, SafeArea
Menu Menu Option 1 Description
Keyboard
Shortcut
Manage
LUTs
Load New LUT Opens the Windows Explorer browser used to navigate to and load a 3d
Mesh or a .cube LUT le.
Delete LUT Opens a list of the currently loaded LUTs that you can select for deletion.
Delete All LUTs Deletes all currently loaded LUTs.
Create
Setup
Opens a dialog box for naming and saving a new Setup le. This le will have
the current operational settings.
Open
Setup
analyzer Selects the "analyzer" Setup le, which is the original setup le which may
have been changed.
(selection list) Reloads the selected Setup le.
Delete
Setup
Deletes the currently open Setup le.
Reset
Setup
Resets the currently open Setup le to factory defaults.
Video Menu Guide
Table 7. Video Menu Options
Menu Menu Option 1 Menu Option 2 Description
Keyboard
Shortcut
Resolution HD HD YCbCr 10Bit
HD RGB 10 Bit
HD RGB 12 Bit
HD RGB Dual-Link 10Bit
HD RGB Dual-Link 12Bit
Denes an HD input video signal.
2K 2K YCbCr 10Bit
2K RGB 10 Bit
2K RGB 12 Bit
2K RGB Dual-Link 10Bit
2K RGB Dual-Link 12Bit
Denes a 2K input video signal.
UHD UHD YCbCr 10Bit
UHD RGB 10 Bit
UHD RGB 12 Bit
UHD Two-Wires Square 10Bit
UHD Two-Wires 2SI 10Bit
Denes a UHD input video signal.
4K 4K YCbCr 10Bit
4K RGB 10 Bit
4K RGB 12 Bit
4K Two-Wires Square 10Bit
4K Two-Wires 2SI 10Bit
Denes a 4K input video signal
AutoDetect
Options
Auto Mode Automatically detects input video
links
Forces 1x SDI Connection
Mode
Forces single link input.
Forced 4x SDI Connection
Mode
Forces four link input.
AutoDetect Toggles Auto Detect of the
incoming video resolution
On or O.
