AJA HDR Image Analyzer User Manual

HDR Image Analyzer v1.0r3 36 www.aja.com
Chapter 6 – Menu Reference
Analyzer Menu Guide
Table 2. Analyzer Menu > Analyzer Mode
Sub Menu Menu Option 1 Description
Keyboard
Shortcut
Analyzer Mode Waveform Luminance Select Luminance Waveform CTRL+F1
Waveform Lumi Color Select Luminance Waveform with Colors CTRL+F2
Waveform Color Select Color Waveform CTRL+F3
Waveform RGB Color Select RGB Color Waveform CTRL+F4
Waveform RGB Select RGB Waveform CTRL+F5
Waveform YCbCr Select YCbCr Waveform CTRL+F6
Waveform YRGB Select YRGB Waveform CTRL+F7
Histogram Luminance Select Histogram Luminance CTRL+F8
Histogram Color Select Histogram Color CTRL+F9
Image Show Single View video image F1
Waveform Show Single View Waveform F2
Gamut Show Single View Gamut F3
Vectorscope Show Single View Vectorscope F4
Combined with Audio Show Quadrants with Audio (either Phase or Level) F5
Combined with Pixel Picker Show Quadrants with Color Picker F6
Combined with Vectorscope Show Quadrants with Vectorscope F7
Combined with Log Show Quadrants with Log F8
Combined with Info Page Show Quadrants with Info Page F9
Single Line Mode Enable Single Line Mode CTRL+space
