AJA HDR Image Analyzer User Manual

HDR Image Analyzer v1.0r3 9 www.aja.com
Chapter 4 – HDR Image Analyzer GUI
Overview
HDR Image Analyzer is a real time video analyzer for QC, Mastering, Grading
and Broadcast. The simple, easy to use graphical user interface features unique
options designed specifically for HDR work. When the HDR Image Analyzer
hardware starts up, the GUI automatically launches.
Views
The Analyzer uses screen layouts with either a Quadrants view or Single view.
Figure 3. Quadrants View Example (Default)
Figure 4. Single View Example, Waveform RGB Color
Drop-Down Menu Navigation
A top menu bar appears when the cursor is moved to the top of the screen. These
menus can be used to select layouts and configure settings. Clicking on a menu
name opens that menu.
