HDR Image Analyzer v1.0r3 7 www.aja.com
Chapter 3 – System Installation
Installation Summary
1. Unpack the shipping box, removing the HDR Image Analyzer, two power
cords, and nine BNC adapter cables.
2. Mount the physical chassis as desired, using the provided sliding rails.
Cooling airow enters the chassis from the front, and exits from the rear and
top panels. Do not obstruct these air vents.
3. Connect the two HDR Image Analyzer power cords to mains AC. For
redundancy, use both power supplies and connect them to separate branch
circuits so that the HDR Image Analyzer will continue to operate even if a
circuit breaker opens on one branch.
4. Connect a computer monitor (user supplied) to one of the rear DisplayPort
ports.
5. Connect a keyboard and mouse (user supplied) to available rear USB 3.0
connectors.
6. Connect the 1.0/2.3 DIN to full-size BNC adapter cables to the
HDR Image Analyzer inputs and output connectors.
7. Connect the HDR Image Analyzer inputs to your video source, and outputs
to your mastering display monitor, if used.
8. Power up the chassis. The system will boot up to the Analyzer application.
Hardware Installation
Shipping Box Contents
An HDR Image Analyzer is shipped with two AC power cords. Rackmount brackets
are provided as part of the chassis.
As you unpack the shipping box, carefully examine the contents. Ensure you
received everything and that nothing was damaged during shipment. If you find
any damage, immediately notify the shipping service and supply them with a
Description of the damage. AJA will repair or replace damaged items.
If you find shipping damage, contact your AJA dealer or distributor for details on
how to have your HDR Image Analyzer repaired or replaced.
NOTE: Save packing materials and the shipping box. If your HDR Image Analyzer ever
requires service or you move your system, use the packaging materials and box
for safe shipment.
Rack Mounting the Chassis
Install the HDR Image Analyzer chassis into a standard 19-inch wide equipment
rack, allowing space for cooling airflow. The chassis occupies only one vertical
rack unit.
Two rack rail assemblies are included in the rack mounting kit. Each assembly
consists of two sections: an inner fixed chassis rail that secures directly to the
server chassis and an outer fixed rack rail that secures directly to the rack itself.
