Brightness and Gamut Bars

This view also contains two bars: the brightness bar on the left indicates the

brightest pixel detected, the gamut bar on the right shows if the colors are within

the legal color gamut. The maximum values are calculated using the Tolerance

parameters available in the Settings Screen. The P3 color space is the limit.

Framing Guides

HDR Image Analyzer supports two framing guides, Safe Title and Safe Action.

Enabling "Safe Area on Image" displays the guides configured in the SAFEAREA

sub-page of the Settings screen. You can display either the Safe Title, Safe Action,

or both boundaries. The CTRL+s hotkey combination enables and disables the

framing guide display.

Figure 18. Framing

Timecode on Image

The timecode is captured from several areas including the SDI and may be

displayed on the image by selecting the Window › Timecode on Image menu

option.
