HDR Image Analyzer v1.0r3 5 www.aja.com
Chapter 1 – Introduction
Overview
AJA's HDR Image Analyzer simplifies monitoring and analysis of 4K/UltraHD/2K/
HD, HDR and WCG content in production, post, quality control (QC) and
mastering. Tools include waveform, histogram, and vectorscope displays and Nit-
level HDR monitoring.
Combining AJA’s production-proven and powerful video and audio I/O with HDR
analysis tools from Colorfront in a compact 1RU chassis, the HDR Image Analyzer
offers a flexible solution for monitoring and analyzing HDR formats including PQ
(Perceptual Quantizer), Hybrid Log Gamma (HLG) and Rec.2020 for 4K/UltraHD
workflows. Colorfront has exclusively licensed its Colorfront Analyzer software to
AJA.
Software Features
• Precise, high quality UltraHD UI for native-resolution picture display
• Advanced out of gamut and out of brightness detection with error tolerance
• Support for SDR (Rec.709), ST2084/PQ and HLG analysis
• CIE graph, Vectorscope, Waveform
• Out of gamut false color mode to easily spot out of gamut/out of brightness
pixels
• Data analyzer with pixel picker
• Up to 4K/UltraHD 60p over 4x 3G-SDI inputs
• SDI auto signal detection
• File base error logging with timecode
• Display and color processing look up table (LUT) support
• Line mode to focus on a single horizontal line as the region of interest
• Loop through output to broadcast monitors
• Still store
• Nit levels, audio levels, and phase metering
• Built-in support for color spaces (including camera colorspaces)
Hardware Features
• One RU height chassis
• Hot swappable redundant power supplies
• Four DisplayPort outputs
• Four USB 3.0 connectors
• Two Network Interface Cards
• Three year warranty
