Io XT/4K Capture, Display, Convert v14.0 63 www.aja.com
Video Output Analog
• Composite/S-Video (Y/C) (1 x BNC/2 x BNC+adapter)
• NTSC, NTSCJ, PAL
• Component (3 x BNC)
• HD: YPbPr, RGB
• SD: YPbPr, RGB (component mode)
• SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB
• 12-bit D/A, 8x oversampling
• +/- .2 dB to 5.0 MHz Y Frequency Response
• +/- .2 dB to 1 MHz C Frequency Response
• .5% 2T pulse response
• <1% Di Phase
• <1% Di Gain
• <1 ns Y/C delay inequity
Audio Input Digital
• 16-Channel, 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate,
synchronous
• 8-Channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Digital
• 16-Channel, 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate,
synchronous
• 8-Channel, 24-bit HDMI embedded audio, 48 kHz sample rate, synchronous
Audio Output Analog
• 8-Channel, 24-bit D/A analog audio, 48 kHz sample rate, balanced, using
industry standard 8 x XLR on DB-25 breakout cable (Breakout cable NOT
included)
• +24dbu Full Scale Digital (0dbFS)
• +/- 0.2db 20 to 20 kHz frequency response
Downstream Keyer
• Supports graphics with alpha channel over video, matte or framebuer, or
framebuer content over incoming video or matte
Up-conversion
• Hardware 10-bit
• Anamorphic: fullscreen
• Pillarbox 4:3: results in a 4:3 image in center of screen with black sidebars
• Zoom 14:9: results in a 4:3 image zoomed slightly to ll a 14:9 image with black
side bars
• Zoom Letterbox: results in image zoomed to ll full screen
• Zoom Wide: results in a combination of zoom and horizontal stretch to ll a
16:9 screen; this setting can introduce a small aspect ratio change
Down-conversion
• Hardware 10-bit
• Anamorphic: full-screen
• Letterbox: image is reduced with black top and bottom added to image area
with the aspect ratio preserved
• Crop: image is cropped to t new screen size
