Io XT/4K Capture, Display, Convert v14.0 64 www.aja.com
Cross-conversion
• Hardware 10-bit
• 1080i to 720p
• 720p to 1080i
• 720p to 1080PsF
SD to SD aspect ratio conversion
• Letterbox: This transforms SD anamorphic material to a letterboxed image
• H Crop: Will produce a horizontally stretched eect on the image; transforms
anamorphic SD to full frame
• SD Pillarbox: Will produce an image in the center of the screen with black
borders on the left and right sides and an anamorphized image in the center
• V Crop: Will transform SD letterbox material to an anamorphic image
Reference Input or LTC Input
• 1 x BNC assignable to Reference video or LTC input
Reference
• Analog Color Black (1V) or Composite Sync (2 or 4V)
• Nonterminating
Electrical Interface
• Thunderbolt 1 (2 x)
Machine Control
• RS-422, Sony 9-pin protocol
• 9-pin D-connector pinout is as follows:
1 GND
2 RX-
3 TX+
4 GND
5 No Connection
6 GND
7 RX+
8 TX-
9 GND
Shell GND
Size (w x d x h)
• 8.74" x 7.09" x 1.65" (222mm x 180mm x 42mm)
Weight
• 1.75 lbs (0.9 kg)
Power
• 10-20V, 18W typical, 22W max
Environment
• Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
• Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140
degrees F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
