Installation 15 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
7.1.3.2.3 Digital outputs
Supply line Pin Function Pin
VDD_7 57
output DIGOUT 16 14
output DIGOUT 17 10
output DIGOUT 18 6
output DIGOUT 19 2
VDD_8 58
output DIGOUT 20 3
output DIGOUT 21 7
output DIGOUT 22 4
output DIGOUT 23 8
7.1.3.2.4 Analogue outputs*
Function Pin
output ANA_out0 39
output ANA_out1 35
output ANA_out2 31
output ANA_out3 27
output ANA_out4 23
output ANA_out5 19
output ANA_out6 15
output ANA_out7 11
7.1.3.2.5 Analogue inputs*
Function Pin
Input ANA_in0 43
Input ANA_in1 47
7.1.3.2.6 CANopen interface*
Function Pin
CANH 38
CANL 42
CANGND 46
7.1.3.2.7 RS422/485 interface*
RS422 RS485
Function Pin
Tx+ 24
Tx- 28
Rx+ 32
Rx- 36
GND 30
Function Pin
A 40
B 44
Jumper
24
32
Jumper
28
36
GND 30
