Installation 16 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
7.1.3.2.8 Auxiliary
Function Pin
Input 16
Output* 20
10,5 V ref* 12
7.1.3.2.9 Option Cable control connector
Function Pin
+ Transmitter supply 1
Transmitter connected 2
0 V 3
RS485-A 4
RS485-B 5
Just for T-Rx 1500 *
7.2 Antenna installation
7.2.1 Single antenna
The antenna should be installed on a conductive surface with a minimum size of 50 x 50 cm.
The surface shall be electrically connected to vehicle/machine chassis. The maximum allowed
cable length between receiver and the antenna is 10 meters.
!
Do not paint the antennas. Paint might considerable reduce the radio coverage area.
7.2.2 Dual antennas
Two antennas are to be used for diversity antenna conguration. Each antenna should be
installed on a conductive surface with a minimum size of 50 x 50 cm. The surface shall be
electrically connected to vehicle/machine chassis. The distance between the antennas should
be at least 1,5 m. The maximum allowed cable length between receiver and each antenna is 10
meters.
Note:. It is important to keep mounting surface clear of paint for best electrical contact with
vehicle/machine chassis.
!
Do not paint the antennas. Paint might considerable reduce the radio coverage area.
