Single Wire Seal crimp instructions 26 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
Interface characteristics
Serial interface*
►RS422
Protocol
Baudrate
Termination
On request
1,2 / 4,8 / 9,6 / 19,2 Kbits/s
470 Ω on receive
►RS485
Protocol
Baudrate
Termination
On request
1,2 / 4,8 / 9,6 / 19,2 Kbits/s
470 Ω
CAN interface*
CAN interface
Baud rate
CANopen Node-ID
CANopen Com-prole
CANopen Dev-prole
LSS support
CAN termination
2.0 B, ISO 11
50 kbits/s...1 Mbits/s (default 125 kbits/s)
1..126 (default 32)
CiA DS 301 Version 4
CiA 401 Generic I/O module
Remote node-ID and baud rate
On/Off ( default on )
Just for T-Rx 1500 *
14 Single Wire Seal crimp instructions
14.1 General
14.1.1 Purpose
These contacts are suitable for 0,5-2,5 mm
2
wire, with single wire seal. Each wire is inserted
into a discrete wire seal prior to being crimped into the contact.
This information includes the basic guidelines for the installation of rubber seals and crimping
of AMP MCP-contacts.
The text and illustrations derives from AMP Application specication 114-18050 Rev.D.
14.1.2 Application specication
For full information see AMP application specication 114-18050-1 available at
www.tycoelectronics.com
