Acceptance tests 19 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
9 Acceptance tests
9.1 T-Rx 1000/1500 receiver type
Check that the installed receiver is intended for use on the vehicle/machine where it is installed
9.2 Radio frequency
Check that the used radio frequency is allowed to use.
9.3 Assembly
9.3.1 Receiver
Check that the receiver is xed rmly.
Check that the receiver is not mounted close to heat generating equipment.
Check that the antennas are of a type intended for use on this kind of vehicle/machine and
installed according to manufactures installation manual.
9.3.2 Electrical grounding
Check that the case of the receiver is properly connected to the vehicle/machine chassis
Remove the antenna cables from the receiver.
Measure the resistance between the receiver case and the vehicle/machine chassis.
Measure the resistance between each antenna base and the vehicle/machine chassis.
Reconnect the antenna cables to the receiver
9.4 Supply voltage
Check that the power supply to the receiver is nominal 12 or 24 V DC and inside the allowed
range of 10-32 V DC.
9.5 Functional test
For information how to use the transmitter see the User Manual.
9.5.1 Power on the receiver.
Check that the led “STATUS” on the receiver is ashing green.
9.5.2 Connections receiver- vehicle/machine control system
Make sure that the moving of the vehicle/machine is interlocked before this test.
Activate the transmitter to be used with the receiver.
Check that the functions commanded from the transmitter affects the intended functions on the
vehicle/machine control system.
9.5.3 Tilt test
Only applicable if transmitter is equipped with a tilt switch.
Activate the system.
Tilt the transmitter more than 90°.
Check that the joystick functions are disabled.
