Technical data 25 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
Interface characteristics
Analogue outputs 0-6
Can be congured as....*
► 0-10 V
Max current
Resolution
Accuracy
5 mA
12 bits
±2% FS
► 0-20 mA
Max load
Resolution
Accuracy
400 Ω
12 bits
±2% FS
Analogue output 7
Can be congured as..*
► 0-10 V
Max current
Resolution
Accuracy
5 mA
12 bits
±2% FS
► 0-20 mA
Max load
Resolution
Accuracy
400 Ω
12 bits
±2% FS
► 0-100mA
Max load
Resolution
Accuracy
70 Ω
12 bits
±2% FS
Digital input Aux*
Switch-on level
Switch-off level
Input resistance
>5 V
< 3 V
70 kΩ
Analogue input 0-1
Can be congured as..*
► 0-10 V
Input resistance
Resolution
Precision
30 kΩ
10 bits
±2% FS
► 0-20mA
Input resistance
Resolution
Precision
150 Ω
9 bits
±2% FS
Just for T-Rx 1500 *
