Technical data 24 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
Interface characteristics
RCSS 1-2
Short-circuit and overload protected
Voltage
Current
User supplied 12/24 V DC nominal
Max 3A
PWM outputs 0-15
Can be congured as....*
► PWM output positive switching.*
Short-circuit and overload protected
Switching Voltage
Switching current
Resolution
Switching frequency
User supplied 12/24 V DC nominal
Max 3A
12 bits
50-400 Hz
► Digital output
Short-circuit and overload protected
Voltage
Current
User supplied 12/24 V DC nominal
Max 3A
► Ratiometric*
Supply voltage
Output
Load current
User supplied 12/24 V DC nominal
25% - 75% of supply voltage
Max 10 mA
► Digital input for positive sensor signals*
Switch-on level
Switch-off level
Input resistance
>5 V
<3 V
5 kΩ
Digital outputs16-23
Short-circuit and overload protected
Voltage
Current
User supplied 12/24 V DC nominal
Max 3A
Digital output Aux
Short-circuit and overload protected
Voltage
Current
User supplied 12/24 V DC nominal
Max 0,5A
Ref 10,5V output*
10,5 V stabilized power for external sensors
Max load current 100 mA
Just for T-Rx 1500 *
