Åkerströms T-Rx 1000 User Manual

Technical data 23 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
Interface, available input/output channels in total: 38
Outputs
Possible Congurations
Just for T-Rx 1500 *
Number Type
16 *PWM Positive switching 0 -3 A, 50-400 Hz
or Digital High side 3 A
or *Ratiometric 25% - 75% of VDD
8 Digital 3 A
7 *Analogue 0-10 V / 0-20 mA
1 *Analogue 0-10 V / 0-20 mA or 0-100 mA
2 RCSS 3 A
1 Digital 0,5 A
Inputs*
Possible Congurations
Just for T-Rx 1500 *
Number Type
16 Digital Positive sensor signals
2 Analogue 0-10 V / 0-20 mA
1 Digital Positive sensor signals
Serial interface*
CAN interface* Optional1 or 2 CANopen slaves
Asynchronous interface
Number Type
1 RS422
or RS485
Just for T-Rx 1500 *
