Technical data 22 (38)
Installation Manual T-Rx 1000/1500 FSK12 FSK12 Version: B4 Document-ID: 945814-000 Author: SH
Electromagnetic Compatibility Immunity
ISO 7637-2-2004 12 V 24 V
Pulse 1 -75 V -450 V
Pulse 2a 37 V
Pulse 2b + 10 V +20 V
Pulse 3a supply lines -112 V -150 V
Pulse 3b supply lines +75 V +150 V
Pulse 4 -6 V -12 V
ISO 10605:2001 Powered up Contact 8 kV
Air 15 kV
Unpowered Contact 6 kV
Air 15 kV
Electromagnetic Compatibility Emission
2009/19/EG / ECE Regulations No. 10
Revision3:2008
30 – 1000 MHz
ISO 11452-1 /-5 20 – 100 MHz 60 V/m
ISO 11452-1 /-2 100 – 2000 MHz 30 V/m
ISO 7637-2:2004 +75 / -100 V
Immunity to Environmental Conditions
IEC 60526:2001 IP67
